DMX Dimming
The Digital Multiplexing communication protocol has typically been implemented in theatrical applications, where its versatile control capabilities have proven indispensable in the world of moving and color-changing lights. Like DALI, the DMX standard allows for digital control of individual fixtures via a low voltage communication protocol, but allows for a larger range of digital addresses per DMX “universe” (512 unique addresses for DMX versus 64 for DALI). Unlike DALI, DMX data signals are polarized and the fixture-to-fixture connections must always be daisy-chained. A typical DMX wiring diagram is shown below:
USAI LIGHTING DMX DIMMING SOLUTIONS
DIML8: Our EldoLED DMX dimming driver option dims down to 0.1% at minimum light level. It is available with a wide range of USAI lighting fixtures.
